B302DA-PCIe: 8-Channel AC→TTL Sense Module

B302DA Block Diagram
Module Purpose

Detects 85–265 VAC (line-neutral) presence per channel and reports it as 3.3V TTL to the host via qSlot. Uses PCIe Mini Card mechanically only; PCIe lanes are not used.

Architecture Overview​

Each channel includes AC conditioning (series impedance + full-wave rectifier), optical isolation (opto LED / phototransistor), and TTL output driver. HV and LV domains are physically separated by creepage/clearance rules.

AC Input and Thresholding​

The AC line drives the opto LED through a series impedance network and a full-wave bridge rectifier. When LED current exceeds the threshold, the phototransistor turns on. For industrial use, 1–3 mA LED current is a good balance for power loss and EMC.

Flicker Suppression

Half-wave ripple can cause output chatter. This module applies RC integration at the TTL driver with ~20–50 ms to deliver a stable presence report.

Optical Isolation and TTL Stage​

On the LV side, the output is driven as 3.3V TTL active LOW (AC present → LOW, AC absent → HIGH). Choose push‑pull or open‑drain + pull‑up per host GPIO characteristics.

EMC and Safety​

  • Creepage/Clearance ≥ 6 mm across HV/LV regions and keep‑outs.
  • Current Limiting: Opto LED current remains safe even at 265 VAC peak; series impedance power rating must survive worst‑case faults.
  • Snubber/RC: Add input RC/snubber for transients; ferrite beads on LV side for common‑mode noise.
Electrical Safety

High voltage module. Install and service by qualified personnel only. Do not modify while powered; maintain HV/LV segregation.

qSlot Interface​

qSlot serves as the power and GPIO carrier. 8× TTL outputs map directly to qSlot DIO/GPIO lines; 3.3V, GND, and control lines (e.g., PWR_EN/COMM_EN) operate with the carrier. qSlot uses PCIe Mini Card mechanically only; PCIe differential lanes are not used. Signal rules are optimized for TTL/CMOS levels.

qSlot Reference

See: Qslot – Modular Industrial Slot

Downloads

All design and production sources: Github B302DA

Bu kütüphane, gerçek sahada kullanılan projelerden gelen ihtiyaçlara göre sürekli gelişen bir açık kaynak projedir. Kullanıcı geri bildirimleri, yeni fonksiyonların eklenmesi ve mevcut yapının iyileştirilmesi açısından kritik öneme sahiptir.

Bu kütüphaneyi hem kişisel hem de ticari projelerinde özgürce kullanabilirsin. Herhangi bir lisans kısıtı uygulanmamaktadır; amacım, bu kütüphanenin mümkün olduğunca fazla gerçek dünya projesinde yer almasıdır. Özel bir entegrasyon ihtiyacın, ticari bir planın veya teknik bir sorunun varsa bana e‑posta üzerinden her zaman ulaşabilirsin: akkoyun@me.com Geri bildirimlerini veya kullanım senaryolarını paylaşman, projeyi geliştirmem açısından büyük katkı sağlar.
